DE/GB 88999 MG 560 26-Feb-2025 Ver. 1.1
GB Instruction manual
Massage Gun MG 560
Device and controls
Explanation of symbols
IMPORTANT
Failure to follow these instructions may
result in serious injury or damage to the
device.
WARNING
These instructions must be followed to
prevent possible injury to the user.
CAUTION
These instructions must be followed to
prevent possible damage to the device.
NOTE
These instructions provide useful
additional information regarding
installation and operation.
The massage device must only be used
in enclosed spaces!
Do not use the massage device
in damp rooms (e.g. when bathing or
showering).
LOT number
Manufacturer
Recycling symbols/codes:
These are used to provide
information about the material
and its proper use and
recycling.
GB Safety Instructions
Read the instruction manual carefully before using this device, especially the
safety instructions, and keep the instruction manual for future use. Should
you give this device to another person, it is vital that you also pass on these
instructions for use.
• Only use the appliance for the purpose for which it is intended in accordance with the instructions for
use. Any misuse will invalidate the warranty.
• The unit is not intended for commercial purposes or the medical sector.
for power supply
• Only charge the unit‘s battery using the USB charging cable supplied. Never leave the unit unattend-
ed when it is connected to the mains (for charging) or in operation.
•
gases, paint, etc.)
• Only connect the unit for charging so that the cable and power connector are freely accessible.
• The built-in batteries are not intended for replacement or removal by the end user. If problems occur
with the power supply, contact the customer service.
• This device must only be supplied at safety extra low voltage (SELV) corresponding to the marking
on the appliance.
• To disconnect the unit from the mains, always pull the plug out of the power connection. Do not pull
on the cable!
for special persons
• If you have any health concerns, consult your doctor before use.
•
conditions: Circulatory disorders, varicose veins, aneurysms, open wounds, heart disease, bruises,
skin tears, cancer, phlebitis or thrombosis.
• Do not use the device if you are pregnant. Special care is necessary when the appliance is used on,
by or near children, sick or helpless persons.
• -
lator, or have undergone internal surgery to assess possible risks of using the device.
•
• In case of unexplained pain, if you are undergoing medical treatment and/or using medical equip-
ment, consult your doctor before using the massager.
• Do not use this device to support or replace medical applications. Chronic conditions and symptoms
could be aggravated.
• Keep the device out of the reach of children under 16 years.
• This appliance can be used by children aged 8 years and above and persons with reduced phys-
ical, sensory or mental capabilities or lack of experience and knowledge if they have been given
supervision or instruction concerning use of the appliance in a safe way and understand the hazards
involved.
• Children must not play with the appliance.
before operating the appliance
• Check the massager carefully for damage before each use. Do not operate a defective appliance.
• Do not use the appliance if any damage is visible on the appliance, if it is not working properly, if it has
been dropped or if it has become wet. To avoid hazards, send the unit to the service centre for repair.
when operating the unit
• Do not use the unit when you are sleeping or in bed.
•
• Never use the appliance when driving a vehicle or operating machinery.
• Too long / too frequent use can cause overheating. Always allow the appliance to cool down before
using it again.
• Never place or use the appliance directly next to an electric heater or other heat sources.
• Do not use the appliance on sensitive areas of the body, such as the head, face, spine, shins, backs
of feet or hands, etc.
• This appliance should not massage the skin surface directly to avoid damage to the skin. The mas-
sage part should be covered with clean, dry clothes or a clean, dry towel. It should be pressed and
moved gently. The massage time on the same spot should not exceed 60 seconds.
• Avoid contact of the appliance with pointed or sharp objects.
• Do not cover the appliance when it is switched on. Do not use the appliance under blankets or pillows.
•
holder and the massage heads or directly onto the massage head when switching on. Risk of
injury!
• Do not immerse the appliance in water or other liquids.
•
was connected. Wait until the unit is completely dry.
•
• Never block the ventilation slots of the device.
• The device supports heating and cooling. People who are insensitive to heat and/or cold should
therefore be very careful when using the device or consult their doctor before use.
for maintenance and cleaning
• The unit is maintenance-free. You may only carry out cleaning work on the unit yourself. In the event
of malfunctions or damage, do not repair the unit yourself, as this will invalidate any warranty claims.
Consult your specialist dealer and have repairs carried out only by authorised service centres in order
to avoid hazards.
• Only use accessories intended for the unit and supplied by the manufacturer.
• Cleaning and user maintenance must not be carried out by children without supervision.
Intended
The device is used for thermal self-massage on various parts of the body, e.g. shoulder, calf, buttock or
chest muscles to activate muscles and promote muscle regeneration and stimulate blood circulation.
The device is not intended for medical-therapeutic use. It is not suitable for clinics, massage practices,
wellness studios, etc. The massage device is not a medical device and is not intended for the treatment
of pain. In case of doubt or uncertainty, consult your doctor before use.
Device and controls
1
Hot and cold massage head - suitable for relaxation and beauty massage
2
Round head: Suitable for large muscle groups
3
Cone-shaped head - suitable for massaging deep tissue
4
U-shaped head - suitable for the muscles in the area of the spine
5
USB-C port (charging socket)
6
Handle
7
Heat button
8
Cold button
9
Multifunctional display
0
q
Decrease vibration speed
Scope of delivery
If in doubt, do not operate the unit and contact your dealer or service centre.
The scope of delivery includes:
• 1 medisana Massage Gun MG 560 • 4 Massage heads
• 1 Charging cable, USB-C • 1 storage case • 1 Short instructions
Packaging is recyclable or can be returned to the raw material cycle. Please dispose of packaging
material that is no longer required properly. If you notice any transport damage when unpacking,
please contact your dealer immediately.
Using the unit - Charging the battery
1. Use a 5V mains adapter with an output current of 2A. Connect the supplied USB charging cable to the
adapter and to the USB-C port
5
of the device.
2. The charge status LEDs on the display
9
indicate the charging process. When the battery is ful-
ly charged, the LEDs light up constantly. The device cannot be used during the charging process.
at any time. With a fully charged battery, the device can be used for up to 3 hours (depending on the
selected level and pressure applied).
3. If the remaining charge is below 20%, the battery should be recharged as soon as possible.
Operation
•
be able to use the hot/cold function, you must use massage head
1
.
• Press and hold the
0
button for approx. 2 seconds to switch the appli-
•
0
or „-“
q
to change the massage intensity (level 1 to
10). The level is shown on the display
9
.
Hot/cold function (can ONLY be used WITH MASSAGE HEAD
1
!)
•
7
and
8
. There are 3 Hot & Cold intensities (Hot: 35°C/40°C/45°C - Cold: 20°C/15°C/10°C), which are
shown accordingly on the display
9
.
•
the blood circulation.
• Cold causes the blood vessels to constrict and the skin to contract. Wrinkles quickly become less
-
ually beforehand.
Troubleshooting
• Device cannot be switched on or cannot be charged
Only use the appliance in rooms with the appropriate operating temperature (0 to 40°C). Failure to
do so may result in functional impairments. If the device has been outside the permitted environment,
place it in the correct environment for approx. 2 hours without further use and try charging or switching
it on again.
• Device does not work or does not work normally, battery charge level at 0
Always charge the battery in good time (with approx. 20% charge remaining). Otherwise, the electron-
•
Check whether the head has been attached correctly, see chapter “Operation”. Some force may be
required - if it has been attached correctly, it will not come loose during use.
•
device, switch it on again. However, the massage head may also be blocked. If the device cannot be
switched on again, remove the massage head and check whether it can be attached correctly.
Cleaning and care, storage
•
cool down.
• Only clean the massager with a slightly damp sponge. Never use brushes, harsh cleaning agents,
petrol, thinner or alcohol. Rub the massager dry with a clean, soft cloth. Do not dry on a radiator or
with a hair dryer.
• Never expose the device to direct sunlight or temperatures above 40°C.
• Only use the device again when it is completely dry.
• Store the appliance and all individual parts in a safe, clean, cool and dry, well-ventilated place. Secure
it against falling and shocks.
WARNING
Please ensure that the polythene packing
is kept away from the reach of children!
Technical data
Name and model: medisana Massage Gun MG 560
Power supply: Li-Ion battery 7.4V, 2200mAh
Input: 5V 2.0A
Charging time: < 3.5 hours
Speed: The vibration intensity depends on the massage head used:
Lev-
el
Vibration frequency
Massage head
1
[1/min]
Vibration frequency
Massage head
234
[1/min]
1 1100 1200
2 1200 1400
3 1350 1600
4 1500 1800
5 1650 2000
6 1800 2200
7 1950 2400
8 2100 2600
9 2250 2800
10 2400 3000
Dimensions: approx. 150 × 50 × 160 mm
Weight: approx. 487 g (incl. hot and cold massage head)
Storage conditions: clean and dry
Item number: 88999
EAN number: 40 15588 88999 8
Disposal
This product must not be disposed of together with domestic waste. All users are obliged to
hand in all electrical or electronic devices, regardless of whether or not they contain toxic
substances, at a municipal or commercial collection point so that they can be disposed of in
an environmentally acceptable manner. Consult your municipal authority or your dealer for
information about disposal.
Warranty and repair terms
Your statutory warranty rights are not restricted by our guarantee below. Please contact your dealer or
the service centre in case of a claim under the warranty. If you have to return the unit, please enclose a
copy of your receipt and state what the defect is.
The following warranty terms apply:
1. The warranty period for medisana products is 3 years from date of purchase. In case of a warranty
claim, the date of purchase has to be proven by means of the sales receipt or invoice.
2. Defects in material or workmanship will be removed free of charge within the warranty period.
3. Repairs under warranty do not extend the warranty period either for the unit or for the replacement
parts.
4. The following is excluded under the warranty:
a. All damage which has arisen due to improper treatment, e.g. non-observance of the user
instructions.
b. All damage which is due to repairs or tampering by the customer or unauthorised third parties.
c. Damage which has arisen during transport from the manufacturer to the consumer or during
transport to the service centre.
d. Accessories which are subject to normal wear and tear.
5. Liability for direct or indirect consequential losses caused by the unit are excluded even if the damage
to the unit is accepted as a warranty claim.
medisana GmbH, Carl-Schurz-Str. 2, 41460 NEUSS, GERMANY
In accordance with our policy of continual product improvement, we reserve the
right to make technical and visual changes without notice.
The current version of this instruction manual can be found under
https://docs.medisana.com/88999
.
Information about service can be found here: www.medisana.com/servicepartners
