Practical advice on using the appliance

! Use cookware made from materials which are

compatible with the induction principle (ferromagnetic

material). We especially recommend pans made from:

cast iron, coated steel or special stainless steel adapted

for induction. Use a magnet to test the compatibility of

the cookware.

*

SUITABLE

UNSUITABLE

Cast iron

Enamelled steel

Special stainless steel

Copper,

Aluminium, Glass, Earthenware,

Ceramic, non magnetic Stainless steel

In addition, to obtain the best results from your hob:

• Use pans with a thick, flat base in order to fully utilise the

cooking zone.

• Always use pans with a diameter which is large enough

to cover the hotplate fully, in order to use all the available

heat.

• Make sure that the base of the cookware is always clean

and dry, in order to fully utilise and extend the life of both

the cooking zones and the cookware.

• Avoid using the same cookware which has been used

on gas burners: the heat concentration on gas burners

may distort the base of the pan, causing it not to adhere

correctly.

Safety devices

Pan sensor

Each cooking zone is equipped with a pan sensor device.

The hotplate only emits heat when a pan with suitable

measurements for the cooking zone is placed on it.

The “u” sign on the display appears if after

selecting the cooking zone the pan is not placed on a

heater , or in case of:

• An incompatible pan

• A pan whose diameter is too small

• The pan has been removed from the hotplate.

After 10 sec. with no pan on the heating zone, a warning

beep signal is emmited.

After 60 sec. with no pan on the heating zone,, the heater

switches off.

Overheating protection

If the electronic elements overheat, the number signalizing

the power level starts flashing, and the letter “c” appears

on the display. When the temperature has reached a

suitable level, this message disappears and the hob may

be used again.

Safety switch

The appliance has a safety switch which automatically

switches the cooking zones off after they have been in

operation for a certain amount of time at a particular power

level. When the safety switch has been triggered, the display

shows “0”.

For example: the right rear hotplate is set to 5 and will

switch off after 5 hours of continuous operation, while the

front left hotplate is set to 2 and will switch off after 8 hours.

When one or more keys are activated for more than

10 sec. the touch control. switches off

A warning beep sounds is emmited every 10

sec., while the key/s is/are activated.

With all heaters at zero power during 10 sec. the

Cooktop is switched off.

If the switching off is due to an accidental activa-

tion of keys, the touch control actuates as above.

Buzzer

This can also indicate several irregularities:

• An object (a pan, cutlery, etc.) has been placed on the

control panel for more than 10 seconds.

• Something has been spilt on the control panel.

• A button has been pressed for too long. All of the above

situations may cause the buzzer to sound. Remove the

cause of the malfunction to stop the buzzer. If the cause of

the problem is not removed, the buzzer will keep sounding

and the hob will switch off.

Errors and Alarms

When an error is detected, the whole appliance or the

heater/s are switched off, a beep sounds (only if one or

more heaters are active) and all displays show a ‘F’

letter and the error code (an index number or a letter)

alternately.

If the problem does not disappear by itself, please

contact the Technical Service.

Switching off the hob

Press the button to switch off the appliance - do not

rely solely on the pan sensor.

If the control panel lock has been activated, the controls

will continue to be locked even after the hob is switched

on again. In order to switch the hob on again, you must

first remove the lock function.

! Do not use adapters, diffusers, or metal plates on the

cooking zones .They may have a detrimental effect

upon the hob’s performance, and might damage the

hob’s aesthetics.
