GAS BURNERS

Each burner is contolled by a tap with progressive settings allowing:

* a wider choice of settings from the maximum position to the

lowest and most precise one,

* easier flame regulation according to the pan diameter,

* no risk of cutting off the flame or switching off when the

flame is turned down quickly.

 Turn on the gas tap,

A symbol next to each control knob indicates which burner is lit.

Turn and press in the relevant burner control knob to the

symbol, keeping it pressed in until the flame ignites. On

models fitted with electronic ignition the flame is ignited by an

electric spark. This is operated by the button or by pressing the

knob (for models with ignition under the knob).

For models not fitted with electronic ignition, or if there is no

electric power, light the flame with a match.

     your cooking requirements.

Intermediate positions are available between the ( ) and ( )

settings on the control knob.

 To turn the flame out, turn the control knob back to stop position.

burner is accidentally extinguished, turn the knob to “0”,

wait one minute and then try to ignite again.

PANS

For a proper use of the burners, choose pans which match the

dimensions given below :

* Very fast Ø 18 cm and more

* Fast Ø from 16 to 18 cm

* Semi-fast Ø 12 cm

* Auxiliary Ø 10 cm

Pans with curved, ridged or warped bottoms are not

recommended.



Aluminium pans may leave marks on the enamelled

pan support. These marks can easily be removed with

a damp cloth and a light abrasive product.



Avoid boiling food too intensely. Food is not cooked any more

quickly this way. In fact, it is subjected to severe agitation, which

may cause the food to lose some of its flavour.

To save gas, make sure that the flames do not overlap the bottom

of the pan.

burner with an empty pan.

IGNITION

RECOMMENDATIONS : when the burners are not in service,

the general gas supply tap should always be turned off.

NB: for models fitted with the SAFETY thermocouple, keep

the knob pressed in for a few seconds in order to activate

the safety system. If the knob is released straightaway

there is not time for the safety system to be activated and

the flame goes out. If this happens, repeat the ignition

procedure from the beginning waiting longer after the flame

is lit.

The rapid thermocouple safety device automatically cuts

off the gas supply if the flame is accidentally extinguished.

If there are particular local gas supply conditions which make

ignition difficult, you are advised to repeat the ignition procedure,

turning the knob to “minimum” ( ).

WA:

The inlet and drain hoses can be directed to left or right.

The dishwasher can be connected to either cold or hot water, as

long as it is no hotter than 60°C.

Water pressure mut be between 0,08 MPa and 0,8 MPa. If the

pressure is below the minimum consult the service department

for advice.

The inlet hose must be connected to a tap so that the water supply

can be cut off when the machine is not in use (fig.1). The

dishwasher inlet hose is fitted with a 3/4" threaded connector

(fig.2). The inlet hose "A" should be tightly connected to a 3/4" tap

"B".

The water connection of the dishwasher must be done exclusively

with the pipe supplied. Do not use an old pipe.

If the machine is connected to new pipes or to pipes which have

not been in use for long time, run water through for a few minutes

before connecting the inlet hose. In this way no deposits of sand

or rust will clog up the water inflow filter.

The hose can be hooked over the side of the sink (it must not be

immersed in water, in order to prevent water from being siphoned

back to the machine when this is in operation) Check that there

are no kinks in the inlet and outlet hoses. To extend, if necessary

the intlet hose, contact the Customer Service.

WATER CONNECTION - WATER DRAINAGE

USE

INSTALLATION

4

WA

Take care not to bend or kink the drain hose when connecting it

to the machine so that the water can drain freely from it (fig.4y).

The drain hose must be at least 40 cm above floor level and it

must have an internal diameter af at least 4 cm. It is advisable to

fit an anti-odour air trap (fig.4x).

If necessary, the outlet hose can be extended up to 2,6 m, provided

that it is kept at a maximum height of 85 cm above floor level. For

this, contact Customer Service.

09 GB
