English | 19

Action Figure Page

- Switching off

- Removing the isolator switch

Removing the battery G 331

Working advice “mowing” H 332

Level indicator, grassbox empty/full I 333

Blade maintenance/Blade replacement J 333

Selecting accessories K 334

A)

Accessories shown or described are not included with the

product as standard. You can find the complete selection of

accessories in our accessories range.

Starting Operation

For Your Safety

u Warning! Switch off, remove the isolator switch and

the battery before adjusting or cleaning. The same ap-

plies when the cable to the switch in the handle is

damaged, cut or entangled.

u The blade continues to rotate for a few seconds after

the machine is switched off.

u Caution: Do not touch the rotating blade.

Charging the Battery

The battery is equipped with temperature monitoring that al-

lows charging only in the temperature range between 0 °C

and 35 °C. In this manner, a high battery service life is

achieved.

Note: The battery is supplied partially charged. To ensure

full battery capacity, completely charge the battery in the

battery charger before using for the first time.

The lithium-ion battery can be charged at any time without

reducing its service life. Interrupting the charging procedure

does not cause damage to the battery.

The “Electronic Cell Protection (ECP)” protects the lithium-

ion battery against deep discharging. When the battery is

empty, the product is switched off by means of a protective

circuit: The product no longer operates.

Do not continue to press the On/Off switch after an auto-

matic shut-off of the product. The battery could become

damaged.

Observe the notes for disposal of the battery.

Inserting/Removing the Battery

Note: Using unsuitable batteries can lead to malfunctions or

damage the machine.

Insert the charged battery. Ensure the battery is inserted

correctly.

To remove the battery from the machine, press the battery

unlocking button and pull the battery out.

Charging Procedure

The charging procedure starts as soon as the mains plug of

the charger is plugged into a socket outlet and the battery is

inserted onto the charger .

Due to the intelligent charging method, the charging condi-

tion of the battery is automatically detected and the battery

is charged with the optimum charging current, depending on

battery temperature and voltage.

This gives longer life to the battery and always leaves it fully

charged when kept in the charger for storage.

Meaning of the indication elements on the

charger (AL 3620 CV/AL 3640 CV/AL 36V-20)

Rapid-charging Procedure

The rapid-charging procedure is indicated by

flashing of the green battery charge indicator.

Indication element of the battery: During the

charging procedure, the three green LEDs light up one after

the other and briefly go out. The battery is fully charged

when the three green LEDs light up continuously. The three

LEDs go out again approx. 5minutes after the battery has

been fully charged.

Note: The rapid-charging procedure is only possible when

the battery temperature is within the allowable charging

temperature range, see section “Technical Data”.

Battery charged

Continuous lighting of the green LED indic-

ator indicates that the battery is fully charged.

Additionally, a signal tone sounds for approx.

2seconds, which acoustically indicates that the battery is

fully charged.

Afterwards, the battery can be removed for immediate use.

When the battery is not inserted, continuous lighting of the

LED indicator indicates that the mains plug is inserted in the

socket outlet and that the battery charger is ready for opera-

tion.

Battery Temperature below 0°C or above 45°C

Continuous lighting of the red LED indicator

indicates that the temperature of the battery is

not within the allowable charging temperature

range, see section “Technical Data”. As soon as the allowable

charging temperature range is reached, the battery charger

automatically switches to rapid charging.

When the battery is not within the allowable temperature

range, the red battery LED lights up when inserting the bat-

tery into the battery charger.

No Charging Procedure Possible

If a different malfunction of the charging pro-

cedure is present, this will be indicated

through flashing of the red LED indicator.

The charging procedure cannot be started and the battery

cannot be charged (see section Troubleshooting).

Bosch Power Tools 1 609 92A 5WA | (16.07.2020)
