EN

4

LOADING THE RACKS

CAPACITY: 14 standard place-settings

CLEANING THE FILTER ASSEMBLY

Regularly clean the lter assembly so that the lters do not clog and that

the waste water ows away correctly.

Using the dishwasher with clogged lters or foreign objects inside the l-

tration system or spray arms may cause unit malfunction resulting in loss of

performance, noisy work or higher resources usage.

The lter assembly consists of three lters which remove food residues

from the washing water and then recirculate the water.

The dishwasher must not be used without lters or if the lter is loose.

At least once per month or after every 30 cycles, check the lter assembly

and if necessary clean it thoroughly under running water, using a non-me-

tallic brush and following the instructions below:

1. Turn the cylindrical lter A in an anti-clockwise direction and pull it out

(Fig 1). It is important when reinstalling the lter that the two trian-

gles shown on the zoom meet.

2. Remove the cup lter B by exerting a slight pressure on the side aps (Fig 2).

3. Slide out the stainless-steel plate lter C (Fig 3).

4. In case you nd foreign objects (such as broken glass, porcelain, bones,

fruit seeds etc.) please remove them carefully.

5. Inspect the trap and remove any food residues. NEVER REMOVE the

wash-cycle pump protection (shown by an arrow) (Fig 4).

After cleaning the lters, replace the lter assembly and x it in position cor-

rectly; this is essential for maintaining the ecient operation of the dishwasher.

CARE AND MAINTENANCE

2

1

4

3

A

A

B

C

TOP RACK

The top rack provides

a targeted cleaning

Wash Zone for bowls,

mugs, even big plates

and cutlery that you’d

normally load in the

lower racks, making

extra space for the

rest of the day’s dishes.

A separate arrangement of the cutlery makes

collection easier after washing and improves

washing and drying performance.

Knives and other utensils with sharp edges

must be positioned with the blades facing

downwards.

UPPER RACK

Load delicate and light dishes: glasses, cups,

saucers, low salad bowls.

The upper rack has tip-up supports which can

be used in a vertical position when arranging

tea/ dessert saucers or in a lower position to

load bowls and food containers.

(loading example for the upper rack)

Adjusting the height of the upper rack

The height of the upper rack can be adjusted: a high po-

sition to place bulky crockery in the lower basket and

a low position to make the most of the tip-up supports

by creating more space upwards and avoiding collision

with the items loaded into the lower rack.

The upper rack is equipped with an Upper Rack height

adjuster (see gure), without pressing the levers, lift it

up by simply holding the rack sides, as soon as the rack is

stable in its upper position. To restore to the lower posi-

tion, press the levers A at the sides of the rack and move

the basket downwards.

We strongly recommend that you do not adjust the height of the rack

when it is loaded. NEVER raise or lower the basket on one side only.

Foldable aps with adjustable position

The side foldable aps can be folded or unfold-

ed to optimize the arrangement of crockery in-

side the rack. Wine glasses can be placed safely

in the foldable aps by inserting the stem of

each glass into the corresponding slots.

Depending on the model:

• to unfold the ap there is needed to slide it up

and rotate or release it from the snaps and pull

it down.

• to fold the ap there is needed to rotate it and

slide the ap down or pull it up and attach the

ap to the snaps.

LOWER RACK

For pots, lids, plates, salad bowls, cutlery etc. Large plates and lids should

ideally be placed at the sides to avoid interferences with the spray arm.

The lower rack has tip-up supports which can be used in a vertical position

when arranging plates or in a horizontal position (lower) to load pans and

salad bowls easily.

(loading example for the lower rack)

POWER CLEAN®

Power Clean® uses the special water jets in

the rear of cavity to wash more intensively

the powerful dirty items. The lower rack has

a Space Zone, a special pull-out support in

the rear of the rack that can be used to sup-

port frying pans or baking pans in upright

position, thus taking up less space.

Placing the pots/casseroles faced to the

Power Clean® component please activate

the POWER CLEAN® on the panel.

How to use Power Clean®:

1. Adjust the Power Clean® area G fold-

ing down the rear plate holders to load

pots.

2. Load pots and casseroles inclined verti-

cally in Power Clean® area. Pots have to

be inclined towards the powerful water jets.

Cutlery basket

It is tted with top grids for im-

proved cutlery arrangement.

It must only be positioned at the

front of the lower rack.

Knives and other utensils with

sharp edges must be placed

in the cutlery basket with the

points facing downwards or

they must be positioned hori-

zontally in the tip-up compart-

ments on the upper rack.
