ENGLISH

4

3. OPERATING INSTRUCTIONS

The Power indication light will turn on when the unit is plugged in,

regardless of whether the unit is operating or not.

1. Turn on/off

Press to start the unit, when the unit is stop; or press to

shutdown it, when the unit is operating.

2. Humidity setting

Press the key to enter humidity-setting state, then press ▲

or ▼ to adjust the humidity from 40% to 80%, every setting is

5%, the LED flashing display when adjusting. Stop pressing for

5 seconds, it will return to normal display. The default value of

humidity is 40%.

3. Fan-speed setting

Press to set the fan speed to high or low, and the corre-

sponding fan speed light will be lighted.

4. Swing setting

After the machine is started, press to start or stop the air-

outlet leaf’s swing.

5. Time-setting

Press to enter boot-time setting state when the unit is stop,

then the LED will display the time, you may press ▲ or ▼ button

to adjust the automatic boot time from 1 to 24 hours. Press

to enter shutdown-time setting state when the unit is running,

then the LED will display the time, you may press ▲ or ▼ button

to adjust the automatic shutdown time from 1 to 24 hours. The

programmed time remains unchanged if the machine stops to

work due to water full or during defrosting. Once turned on or

off by user, the timer function will be canceled.

4. DRAINING THE COLLECTED WATER

When the drainage tank is full, the tank full indicator light will turn

on, the operation will stop automatically and the buzzer will beep

15 times to alert the user, that the water need to be emptied from

the drainage tank.

5. EMPTYING THE DRAINAGE TANK

1. Lightly press on the sides of the tank with both hands and pull

the tank out gently.

2. Discard the collected water.

NOTE

1. If the drainage tank is dirty, wash it with cold or lukewarm water.

Do not use detergent, scouring pads, chemically treated dust

cloths, gasoline, benzene, thinner, or other solvents, as these

can scratch and damage the tank and cause water leakage.

2. When replacing the drainage tank, press the tank firmly into

place with both hands. If the tank is not positioned properly, the

“TANK FULL” sensor will be activated, and the dehumidifier will

not operate.

6. CONTINUOUS WATER DRAINAGE

The unit features a continuous drainage port. Using a plastic pipe

(with an inner diameter of 10 mm) inserts into drain hole (on inter-

mediate plate), reach out from side of water tank, install it in place,

and arrange the drain pipe.

The water in the drainage tank can be continuously drained out

from the continuous port on the unit.
