Manuale Karlsson KA6026YE Orologio

Manuale

(1) Volume Switch

(2) Battery Compartment 1

(3) Soft Set Button

(4) Battery Compartment 2

(5) Time Setting Knob

(6) Pendulum

1. Attach the pendulum to the clock movement.

2.

Insert 2 “AA” size batteries into the Battery Compartment 1 (2) and 1 “AA” size battery into the Battery Compartment 2

(4) as the positive terminals and negative terminals indicated, adjust the Time Setting Knob (5) to set the time.

3.

The Volume Switch (1) has left (silence), middle (low) and right (high) three levels. Please move it to the position you

need.

4. To set the bird voice playing correctly, please do as follows:

(As the programmed silent time is from 22:00 to 5:00 per day, the initial bird voice playing time starts at six o’clock in

the morning. You need to tell the clock the setting time (local current time) is in the period of day or night.)

If the setting time is from 5:00 to 5:59, no need to press any button.

If the setting time is from 6:00 to 6:59, press the Soft-Set Button (3) only once.

If the setting time is from 7:00 to 7:59, press the Soft-Set Button (3) quickly and continuously twice.

If the setting time is from 8:00 to 8:59, press the Soft-Set Button (3) quickly and continuously three times.

If the setting time is from 9:00 to 9:59, press the Soft-Set Button (3) quickly and continuously four times.

...

If the setting time is from 4:00 to 4:59, press the Soft-Set Button (3) quickly and continuously

twenty three times.

Please see the following table for the detailed pressing times:

4. Please keep this instruction paper in a safe place for future use.

Setting

time

5:00

to

5:59

6:00

to

6:59

7:00

to

7:59

8:00

to

8:59

9:00

to

9:59

10:00

to

10:59

11:00

to

11:59

12:00

to

12:59

13:00

to

13:59

14:00

to

14:59

15:00

to

15:59

16:00

to

16:59

Pressing

times

0 1 2 3 4 5 6 7 8 9 10 11

Setting

time

17:00

to

17:59

18:00

to

18:59

19:00

to

19:59

20:00

to

20:59

21:00

to

21:59

22:00

to

22:59

23:00

to

23:59

0:00

to

0:59

1:00

to

1:59

2:00

to

2:59

3:00

to

3:59

4:00

to

4:59

Pressing

times

12 13 14 15 16 17 18 19 20 21 22 23

INSTRUCTION MANUAL WALL CLOCK GRATO CUCKOO KA6026

1. Attach the pendulum to the clock movement.

2. Insert 2 “AA” size batteries into the Battery Compartment 1 (2) and 1 “AA” size battery into the Battery Compartment 2 (4) as the positive terminals and negative

terminals indicated, adjust the Time Setting Knob (5) to set the time.

3. The Volume Switch (1) has left (silence), middle (low) and right (high) three levels. Please move it to the position you need.

4. To set the bird voice playing correctly, please do as follows:

(As the programmed silent time is from 22:00 to 5:00 per day, the initial bird voice playing time starts at six o’clock in the morning. You need to tell the clock the setting

time (local current time) is in the period of day or night.)

If the setting time is from 5:00 to 5:59, no need to press any button.

If the setting time is from 6:00 to 6:59, press the Soft-Set Button (3) only once.

If the setting time is from 7:00 to 7:59, press the Soft-Set Button (3) quickly and continuously twice.

If the setting time is from 8:00 to 8:59, press the Soft-Set Button (3) quickly and continuously three times.

If the setting time is from 9:00 to 9:59, press the Soft-Set Button (3) quickly and continuously four times.

If the setting time is from 4:00 to 4:59, press the Soft-Set Button (3) quickly and continuously twenty-three times.

Please see the following table for the detailed pressing times:

4. Please keep this instruction paper in a safe place for future use.

1. Volume switch

2. Batterij compartment 1

3. Soft Set Button

4. Battery compartment 2

5. Time setting knob

6. Pendulum
