Manuale ION Pure LP Giradischi

Manuale

4

Features

1. Platter – Place your record here.

2. 45 RPM Adapter Holder – Holds the

included 45 RPM adapter. When not

using the adapter, please place it in this

holder.

3. Tonearm – The tonearm can be raised

and lowered by hand, or by pressing the

raise / lower lever. Please note that the

tonearm needs to be moved away from

resting position (on the arm clip) for the

turntable motor to activate. When the

tonearm is placed back in its resting

position, the turntable motor will

deactivate.

4. Arm Clip – This specially designed arm

clip secures the tonearm while at rest or

when not in use. The arm clip has been

designed to remain in the up position

while unlocked.

5. Raise / Lower Lever – Raises and lowers

the tonearm.

6. 33 / 45 / 78 Switch* – This switch controls

the RPM of the turntable platter.

Note: For best results when playing 78 RPM

vinyl records, use a 78 stylus (sold

separately). Only use a 78 stylus with 78

RPM vinyl records. Purchase the iCT06rs 78 stylus at

ionaudio.com/ict06rs.

7. Autostop switch – This switch turns autostop on or

off. When autostop is on, the platter will start spinning

when the tonearm is placed over the record and stop

spinning when the record has reached the end. (When

autostop is off, the platter will always spin regardless

of the position of the tonearm.)

Note: If your vinyl record stops before it reaches the

end of the music, turn Autostop to the off position for

this particular record. This is generally recommended

for 45 RPM records.

8. RCA Output** – The audio from a playing vinyl record

is sent to this line-level coaxial audio output. This must

not be connected to phono level devices.

9. USB Audio Output – Use the included USB cable to

connect your turntable to your computer. The USB

connection will send audio from the turntable to your computer. Please see the Using Pure LP With

Your Computer section of this manual for information.

10. Power – Use the included adapter to connect to wall power.

11. Power Button – Press this button to turn PURE LP on/off.

7

2

7

1

7

3

7

4

7

5

7

6

7

7

PURE LP

IMPORTANT: Remove the plastic

cartridge cover (needle cover) before

o

p

eratin

g

the turntable.

**WARNING: The RCA outputs are LINE

level. Please only connect these to LINE

level inputs. You may damage your

receiver if you plug in a LINE level device

into a PHONO level input.

* If needed, you may adjust the speed of

the turntable platter. On the underside of

PURE LP, remove the rubber pads and

tighten/loosen the appropriate screw with

a screwdriver.

8

9

10

11
