EN7

For best performance, when you use two pots simultaneously, put them according to the pictures below:

NOTE:

When making quick-cook foods that require perfect heat distribution (e.g. pancakes) on the 28 cm double cooking zone (where present), use pans no greater than

24 cm in diameter. For delicate cooking (for example, melting chocolate or butter) use the smaller diameter single zones.

After unpacking the product, check for any damage during transport. In case of problems, contact the dealer or the After-Sales Service.

For built-in dimensions and installation instruction, see the pictures in page 2.

PREPARING THE CABINET FOR FITTING

RECOMMENDED POT POSITION

POWER LEVEL TABLE

Power level Type of cooking Level use

(indicating cooking experience and habits)

Max. power

Boost Fast heating

Ideal for rapidly increasing the temperature of food to fast boiling in the case of water or rapidly heating

cooking liquids

9-7

Frying - boiling

Ideal for browning, starting to cook, frying frozen products, fast boiling

High power

Browning - slow frying - boiling

- grilling

Ideal for slow frying, maintaining a high boil, cooking and grilling (short duration, 5-10 minutes)

7-5

Browning - cooking - stewing -

slow frying - grilling

Ideal for slow frying, maintaining a low boil, cooking and grilling (medium duration, 10-20 minutes),

preheating

Medium power

Cooking - stewing -

slow frying - grilling

Ideal for stewing, maintaining a gentle boil, cooking and grilling (long duration).

4-3

Cooking - simmering -

thickening - creaming pasta

Ideal for prolonged cooking (rice, sauces, roasts, fish) with liquids (e.g. water, wine, broth, milk),

creaming pasta.

Ideal for prolonged cooking (volumes of less than a litre: rice, sauces, roasts, fish) with liquids

(e.g. water, wine, broth, milk)

Low power 2-1

Melting - defrosting -

keeping food hot -

creaming risottos

Ideal for softening butter, gently melting chocolate, thawing small products and keeping just-cooked

food hot (e.g. sauces, soups, minestrone)

Ideal for keeping just-cooked food hot, creaming risottos and keeping serving dishes warm

(with induction-suitable accessory),

OFF

Zero

power

Support surface

Hob in standby mode or off (possible end-of-cooking residual heat, indicated by “H”)

INSTALLATION

WARNING

- Install a separator panel under the hob.

- The lower part of the product must not

be accessible after installation.

- Do not fit the separator panel if an

undertop oven is installed.

• The distance between the underside of the appliance and the separator panel must respect the dimensions given in the figure.

• In order to ensure the correct operation of the product, do not obstruct the minimum required clearance between the hob and the top of the unit (min. 5 mm).

• If an undertop oven is installed, make sure the oven is equipped with a cooling system.

• Do not install the hob above a dishwasher or washing-machine, so that the electronic circuits do not come into contact with steam or moisture which could damage them.

• To remove the hob, use a screwdriver (not provided) to prise off the perimeter clips on the underside of the appliance.

6-7 cm

min. 20 mm

min. 5 mm

57

75

80
