When installing a hood above the hob, please consult the installation

requirements specified for the hood but, in any case, the distance

between the hob and the hood must not be lower than 700 mm.

When installing an oven under the hob, separator must not be put and

the minimum distance between the bottom part of the hob and the

oven must not be lower than 10 mm. Do not install not cooled oven

under this hob and install the oven following its own installation

requirements. (see Figure 5)

Leave a distance of at least 55 mm between the hob and the back wall

and of at least 150 mm between the hob and the vertical furniture or

walls in the lateral side. If a furniture is installed above the hob, the

minimum distance required is 700 mm.

(see Figure 3)

If the bottom part of the hob is adjacent to an area normally accessible

for handling or cleaning operations, a separator it must be put 20 mm

below the bottom part of the hob. (see Figure 4)

PRODUCT CODE T

Identification Plate (located under the hob's bottom casing)

1. PROTECTION OF THE ENVIRONMENT

• WEEE shall not be threatened as household waste.

This appliance is marked according to European

Directive 2012/19/EU on Waste Electrical and

Electronic Equipment (WEEE).

WEEE contains both polluting substances (which

can cause negative consequences for the

environment) and basic components which can be

reused.It is important to have WEEE subjected to

specific treatments, in order to remove and dispose

properly all pollutants and recover and recycle all

materials.

• WEEE shall be handled over to the relevant collection points

managed by the municipality or by registered companies. In many

Countries, for large WEEE, home collection could be present.

• In many Countries, when you buy a new appliance, the old one

may be returned to the retailer who has to collect it free of charge on

a one-to-one basis, as long as the appliance is of equivalent

typology and has the same functions as the supplied one.

Individuals can play an important role in ensuring that the WEEE

does not become an environmental issue; it is essential to follow

some basic rules:

2. INSTALLATION

In addition, all decorative laminates should be fixed with high-resistance

glue.

Appliance can be installed in a Built-in furniture in Standard (see igure

) or lush (see Figure 2) mode.

Installing a domestic appliance it is a complicated operation which, if

not carried out correctly, can seriously have impact on safety of goods,

properties or people. or this reason, it should be carried out by a

professionally qualified person in accordance with technical

regulations.

In the event that this advice it is ignored and installation is carried out

by an unqualified person, the Manufacturer declines all responsibility

for any technical failure of the appliance whether or not it results in

damage of goods or properties or in inury of people or animals.

After having removed the packaging please be sure that the appliance

it is not damaged, otherwise contact the Retailer or Manufacturer After

Sales Service.

Make sure that the furniture in which the appliance will be fitted and all

other furniture in the nearby are made with materials which can

withstand high temperatures (min  C).

Worktop thickness should be between 25 and 45 mm.

Do not use the hob until the silicone layer it is completely dry.

Normal Fixing:

- Get the fixing clips from accessory bag and screw them into the

position shown on bottom box. (Do not tighten the screws to block

clips, they should move freely) (see Figure 7)

- Turn the clips and tighten them fully. (see Figure 8)

Press the sides of hob until it is supported around its entire perimeter.

(see Figure 10)

Get four springs form accesory bag and screw them onto bottom box

as shown in figure. (see Figure 9)

FLUSH INSTALLATION

- Insert the hob in center position of cut out.

Center and insert the hob.

A watertight seal gasket is supplied with the hob. Fit the seal gasket

around the bottom hob as described and make sure that it is properly

fitted to avoid any leakage into the supporting furniture. (see Figure 6)

Quick Fixing: (Depending on model)

After checking that the position of the hob is correct fill the gap

between the worktop and the hob with silicone adhesive. Flatten the

silicone layer with a scraper or with wet finger damped with water and

soap before it forms.

supported around its entire perimeter. (see Figure 11)

05 GB

Note: er erieer iesis re se i sr isi

3. ELECTRICAL CONNECTION

A

B

C D

A

B

C

A

C

B

C

A B

D

A

B

C

D

LAYOUT 1-3 LAYOUT 2-4

LAOUT 1-3

LAOUT 2-4

1

2

5

5

7

3

5

5

6

6

6

6

6

6

5

5

3

1

2

4

5

5

6

6

1

2

3

6

6

6

4

5

5

5

6

6

5

5

3

1

2

5

5

6

6

1

2

3

6

6

6

5

5

5

1-3

2-4





7

LAOUT
