• RESIDUAL HEAT INDICATOR
The control panel tells the user when the surface temperature of
the cooking zones exceeds about 60°C, by the following displaying:
. When the temperature goes back below 60°C, the display
goes off.
For ending the cooking, we advise switching off the cooking zone
and using the residual heat of the zone to finish cooking gently.
N.B. After a cut in the current, the residual heat indicator disappears
completely, even if the surface temperature exceeds 60°C.
• OPERATING THE ADDITIONAL COOKING ZONE
(TWO ZONES)
The cooking zone with two zones is fitted certain models. It can
be either concentric or extendable.
It is active in totality when the cooking zone is in function ;
the control led of the additional cooking is displayed.
To desactivate the additional cooking zone :
- Press on the additional cooking zone button . The corresponding
control led for the additional cooking zone goes off when it is
desactivated.
To re-activate the additional cooking zone :
- Press on the additional cooking zone button . The corresponding
control led for the additional cooking zone is active.
• OPERATING THE ADDITIONAL COOKING ZONE
(THREE ZONES)
The additional cooking zone is fitted only one model.
It is active in totality when the cooking zone is in function ;
the two control leds of the additional cooking are displayed.
To desactivate the additional cooking zones :
- Press one time the additional cooking zone button . The
corresponding control led for the external additional cooking
zone goes off when it is desactivated.
- Press two times the additional cooking zone button . The
corresponding control led for the central additional cooking zone
goes off when it is desactivated.
To re-activate the additional cooking zones :
- Press on the additional cooking zone button, one or two times
on the additional cooking zone button, according to the need.
• PROGRAMMING A COOKING ZONE (according to the model)
Every cooking zone can be programmed for a maximum time of
99 minutes.
- Start the required zone by following the previous instructions.
The control LED near the heat level must be displayed, it shows
that the zone is live.
- Press the Timer button.
The zone mark around the timer display shows the controlled
zone.
- Press again on the timer button to select a time in minutes
between 0 and 99 minutes or press on the "-" button to decrease
the time between 60 minutes and 0.
the programmed time can be modified at any moment reactivating
the cooking zone and then the timer button.
When the time is run, the cooking zone goes off automatically
and an audible beep sounds for 1 minute, press the timer button
to stop it.
the time can be used alone as reminder, it will ring at the end of
the programmed time.
The locking function prevents the children from starting the hob.
It is also used for cleaning the control strip as the controls can be
locked without the hob being on.
To lock the hob :
- Press the on/off button .
- Press simultaneously " - " button and " + " button of the front
right zone (CH 633 front left zone), and then press again on
the " + " button of this zone. The hob is locked, the locking
indicator " L " is displayed on all zones for 20 seconds.
To unlock the hob :
- Press the on/off button . The locking indicator " L " is displayed
on all zones.
- Press simultaneously the " - " button and the " + " button of the
front right zone (CH 633 front left zone), and then press again
on the " - " button of this zone.
The hob is unlocked.
• LOCKING BUTTON OPERATION
• FAST HEATER OPERATION
Starting the fast heater
- Press the on/off button .
- Start the required zone, press the " + " button to obtain position
“9”, release the button briefly and press again the " + " button ;
the display alternates showing "A" “fast heater” and "9" heat
level.
- If necessary reduce to the required heat position, the display
alternates showing "A" “fast heater” and the new heat position.
Cooking
position
Power
released
(%)
Time of
fast heater
(minutes)
Maximum
operating
time before
automatic
cut off*
0 : 0 % : 0 : 0 H
1 : 3 % : 1 : 6 H
2 : 6 % : 3 : 6 H
3 : 11 % : 5 : 5 H
4 : 16 % : 6,5 : 5 H
5 : 19 % : 8,5 : 4 H
6 : 32 % : 2,5 : 1,5 H
7 : 45 % : 3,5 : 1,5 H
8 : 65 % : 4,5 : 1,5 H
9 : 100 % : 0 : 1,5 H
E.g. 1800 W zone at position 6 = 32% of 1800 W power released
When the “Fast heater” is on, the zone supplies 1800 W power
for 2.5 minutes, and adjusts to 576 W after this time.
* For increased safety, the cooking zones cut off automatically if
they are left on too long. The cut off depends on the heat level
used.
To desactivate the fast heater
- Switch on the cooking zone, press the " - " button to come back
to a normal heat level, decrease to the heat level required or to
" 0 " to stop the cooking zone.
• Before carrying out any maintenance work on the hob, allow it
to cool down.
• Only products, (creams and scrapers) specifically designed for
glass ceramic surfaces should be used. They are obtainable
from hardware stores.
• Avoid spillages, as anything which falls on to the hob surface
will quickly burn and will make cleaning more difficult.
• It is advisable to keep away from the hob all substances which
are liable to melt, such as plastic items, sugar, or sugar-based
products.
MAINTENANCE:
- Place a few drops of the specialised cleaning product on the
hob surface.
- Rub any stubborn stains with a soft cloth or with slightly damp
kitchen paper.
- Wipe with a soft cloth or dry kitchen paper until the surface is
clean.
8. CLEANING AND MAINTENANCE
9 GB-IE
• GENERAL STOP
The cooking zones and the timer can be stopped at any
moment by pressing the On-Off button.
