Manuale Candy CH64BVT/1 Piano cottura

Manuale

Leave a distance of at least 55

mm between the hob and the

back wall and of at least 150

mm between the hob and the

vertical furniture or walls in the

lateral side. If a furniture is

installed above the hob, the

minimum distance required is

700 mm.

When installing a hood above

the hob, please consult the

installation requirements

specified for the hood but, in

any case, the distance between

the hob and the hood must not

be lower than 700 mm.

PRODUCT CODE T

Identification Plate (located under the hob's bottom casing)

1. GENERAL WARNINGS

By placing the mark on this appliance we are assuring

compliance to all European Safety, Health and Environment

requirements which are applicable for this product category.

2. PROTECTION OF THE ENVIRONMENT

• WEEE shall not be threatened as household waste.

WEEE contains both polluting substances (which

can cause negative consequences for the

environment) and basic components which can be

reused.It is important to have WEEE subjected to

specific treatments, in order to remove and dispose

properly all pollutants and recover and recycle all

materials.

Individuals can play an important role in ensuring that the WEEE

does not become an environmental issue; it is essential to follow

some basic rules:

This appliance is marked according to European

Directive 2012/19/EU on Waste Electrical and

Electronic Equipment (WEEE).

• WEEE shall be handled over to the relevant collection points

managed by the municipality or by registered companies. In many

Countries, for large WEEE, home collection could be present.

• In many Countries, when you buy a new appliance, the old one

may be returned to the retailer who has to collect it free of charge on

a one-to-one basis, as long as the appliance is of equivalent

typology and has the same functions as the supplied one.

3 INSTALLATION.

Installing a domestic appliance it is a complicated operation which, if

not carried out correctly, can seriously have impact on safety of goods,

properties or people. For this reason, it should be carried out by a

professionally qualified person in accordance with technical

regulations.

In the event that this advice it is ignored and installation is carried out

by an unqualified person, the Manufacturer declines all responsibility

for any technical failure of the appliance whether or not it results in

damage of goods or properties or in injury of people or animals.

After having removed the packaging please be sure that the appliance

it is not damaged, otherwise contact the Retailer or Manufacturer After

Sales Service.

Make sure that the furniture in which the appliance will be fitted and all

other furniture in the nearby are made with materials which can

withstand high temperatures (min 100 °C).

In addition, all decorative laminates should be fixed with high-resistance

glue.

Appliance can be installed in a Built-in furniture in “Standard” or “Flush”

mode.

700 mm

55 mm

150 mm

490 mm

+ 2

- 0

560 mm

+ 2

- 0

Min. 70 mm

Standard installation

perimeter

Note: Inner perimeter dimensions are same with standard installation

703 mm (70 cm hob)

+ 2

- 0

523 mm

+ 2

- 0

593 mm (60 cm hob)

+ 2

- 0

Slot depth: 5 mm

Flush installation

perimeter

Worktop thickness should be between 25 and 45 mm.

If the bottom part of the hob is adjacent to an area normally accessible

for handling or cleaning operations, a separator it must be put 0 mm

below the bottom part of the hob.

2

min 20 mm

When installing an oven under the hob, separator must not be put and

the minimum distance between the bottom part of the hob and the

oven must not be lower than 10 mm. Do not install not cooled oven

under this hob and install the oven following its own installation

requirements.

10 mm

min

05 GB
