The yellow/green wire of the power supply cable must be connected to

the earth of both power supply and appliance terminals.

To proceed to the new connection, please follow below instructions:

If the appliance has a socket outlet, it must be installed so that the

socket outlet is accessible.

For any questions regarding power supply cord refer to After Sales

Service or a qualified technician.

If the hob is fitted with power supply cord, this shall be connected only

to a power supply of 220-240 V between phase and neutral.

Before making the connection, make sure that the installation is

protected by a suitable fuse, and that it is fitted with wires of a large

enough section to supply the appliance normally.

Manufacturer declines all responsibility for any damage that

might be caused by unsuitable or unreasonable use.

"Installation must conform to the standards & directives."

WARNING: Manufacturer cannot be held responsible for any incident

or its consequences that may arise during the use of an appliance not

linked to the earth, or linked to an earth whose continuity is defective.

Before any electrical operation, please check the supply tension

shown on the electricity meter, the adjustment of the circuit- breaker,

the continuity of the connection to earth to the installation and that the

fuse is suitable.

Turn over the hob, glass side against the working top, taking care to

protect the glass.

It is however possible to connect the hob to:

The electrical connection to the installation should be made according

to the rated power of the Appliance; this should be made via an Omni

pole cut-out switch.

Three Phase 380-415 V2N

Open the cover in the following sequence:

Three Phase 220-240 V3

- find the two tabs located on the sides;

- Strip the end of each conductor of the supply cord on a 10 mm length,

by taking in account the requested length of the cord for the

connection to the terminal block;

- unscrew the cable clamp "1";

- Remove the screws retaining the terminal block which

contains the shunt bars and the conductors of the supply cord;

- Fix the cover;

- Pull out the supply cord.

- Pass the power supply cable into the clamp;

Operations to be carried out to make a new connection:

-According to the installation and with the help of shunt bars which you

should have recovered in the first operation, fix the conductor as

shown on the chart;

- put the blade of a flat screw-driver in front of each tab "2" e

"3", push in and press;

- Screw the cable clamp.

- remove the cover.

- Choose the power supply cable in accordance with the

recommendations in the table;

To release the power supply cord:

Connection to the terminals on the terminal block

ATTENTION:

If it should be necessary to replace the power supply cord, connect the

wire in accordance with following colors/codes:

LAY OUT

"1-6"

LAY OUT

"7"

MONOPHASE or TWO PHASES 220-240 V

~

Cable

HO5V2V2F

Cable

HO5V2V2F

Cable

HO5V2V2F

3x2,5 mm

2

3x4 mm

2

4x1,5 mm

2

4x1,5 mm

2

4x1,5 mm

2

4x1,5 mm

2

THREE PHASES 220-240 V

3~

THREE PHASES 380-415 V2N~

- Screw the cable clamp.

- According to the installation and with the

help of shunt bars which you should have

recovered in the first operation, fix the

conductor as shown on the chart;

- Fix the cover;

- Strip the end of each conductor of the

supply cord on a 10 mm length, by taking in

account the requested length of the cord for

the connection to the terminal block;

Operations to be carried out to make a new connection:

- Pass the power supply cable into the

clamp;

- Choose the power supply cable in

accordance with the recommendations in

the table;

Note: make sure the terminal board screws are tight.

07 GB

2 31

SHUNT

N

=

Neutral

PE

=

EarthL1 / L2 / L3 = Phase

220-240V 3 ~

PE

L1 L2

L3

380-415V 2N ~

N

PE

L1 L2

L3

PE

L1

L2

220-240V ~

N

L

220-240V 2 ~

L2

PE

L1

PE
