09 GB- IE

. STOPPING A COOKING ZONE

- Press the selection button of the required cooking zone.

- Press the "-" button to display heat level . Now the zone goes

off, the indicator goes off after 10 seconds.

- To stop rapidly, press simultaneously the "-" and the

respective cooking zone selection.

The heat level automatically goes down to . The cooking

zone goes off.

. GENERAL STOP

The cooking zones and the timer can be stopped

at any moment by pressing the On-Off button.

. RESIDUAL HEAT INDICATOR

The control panel tells the user when the surface temperature of

the cooking zones exceeds about 60°C, by the following

displaying: . When the temperature goes back below 60°C, the

display goes off.

For ending the cooking, we advise switching off the cooking zone

and using the residual heat of the zone to finish cooking gently.

N.B. After a cut in the current, the residual heat indicator

disappears completely, even if the surface temperature exceeds

60°C.

. OPERATING THE ADDITIONAL COOKING ZONE

(TWO ZONES)

The cooking zone with two zones is

fitted certain models .............................

>

It is active in totality when the cooking zone is in function ; the

control led of the additional cooking is displayed.

To desactivate the additional cooking zone :

- Press again on the additional cooking zone touch. The Led goes

off when it is desactivated.

To re-activate the additional cooking zone :

- Press on the cooking zone button. The Led is active again.

. PROGRAMMING A COOKING ZONE (according to the model)

Every cooking zone can be programmed for a maximum time of

99 minutes.

- Start the required zone by following the previous instructions.

- Press on simultaneously the touch "-" and "+" to activate the

timer, " " is displayed.

- Press again on the "+" button to select a time in minutes

between 0 and 99 minutes or press on the "-" button to decrease

the time between 30 minutes and 0. The timer control led near

the level is displayed.

--> the programmed time can be modified at any moment.

When the time is run, the cooking zone goes off automatically and

an audible beep sounds for 1 minute, press a button to stop it.

--> If any zone is activated, the timer can be used alone, as

reminder, it will ring at the end of the programmed time.

Example

LED

TYPE

B

LED

TYPE

B

7

7

LOCKING BUTTON OPERATION

The locking function prevents the accidental activation of the

hob by children, and it is also useful during the cleaning of the

hob.

TO LOCK THE HOB. (Example for hob with 4 zones)

Press the ON/OFF button and then (only after this operation the

child lock can be activated)

Press simultaneously the minus

key and the top left selection key,

until you hear the beep sound; if

you do not feel a beep sound,

switch OFF the hob and repeat all

the operation of setting.

After press again the top left

selection key.

This operation procedure must

take place within 10 sec, and no

other key than the one described

above may pressed; otherwise the

input will be cancelled for not being completed.

All displays show an “L” for

LOCKED (=child lock against

unintentional activation) – if a

cooking zone is at stage “hot, “L”

and “H” appear alternately.

TO UNLOCK THE HOB

For unlock the control unit, it is

necessary that the minus key and

the top left selection key (cooking

zone back left) are pressed

simultaneously and subsequently

pressing the minus key again.

The looking is now removed and

the Touch Control returns to

STAND BY mode.
