The locking function prevents the children from starting the hob.

It is also used for cleaning the control strip as the controls can be

locked without the hob being on.

To lock the hob :

- Press the on/off button .

- Press simultaneously " - " button and " + " button of the front

right zone (CH 633 front left zone), and then press again on

the " + " button of this zone. The hob is locked, the locking

indicator " L " is displayed on all zones for 20 seconds.

To unlock the hob :

- Press the on/off button . The locking indicator " L " is displayed

on all zones.

- Press simultaneously the " - " button and the " + " button of the

front right zone (CH 633 front left zone), and then press again

on the " - " button of this zone.

The hob is unlocked.

• LOCKING BUTTON OPERATION

• FAST HEATER OPERATION

Starting the fast heater

- Press the on/off button .

- Start the required zone, press the " + " button to obtain position

“9”, release the button briefly and press again the " + " button ;

the display alternates showing "A" “fast heater” and "9" heat

level.

- If necessary reduce to the required heat position, the display

alternates showing "A" “fast heater” and the new heat position.

Cooking

position

Power

released

(%)

Time of

fast heater

(minutes)

Maximum

operating

time before

automatic

cut off*

0 : 0 % : 0 : 0 H

1 : 3 % : 1 : 6 H

2 : 6 % : 3 : 6 H

3 : 11 % : 5 : 5 H

4 : 16 % : 6,5 : 5 H

5 : 19 % : 8,5 : 4 H

6 : 32 % : 2,5 : 1,5 H

7 : 45 % : 3,5 : 1,5 H

8 : 65 % : 4,5 : 1,5 H

9 : 100 % : 0 : 1,5 H

E.g. 1800 W zone at position 6 = 32% of 1800 W power released

When the “Fast heater” is on, the zone supplies 1800 W power

for 2.5 minutes, and adjusts to 576 W after this time.

* For increased safety, the cooking zones cut off automatically if

they are left on too long. The cut off depends on the heat level

used.

To desactivate the fast heater

- Switch on the cooking zone, press the " - " button to come back

to a normal heat level, decrease to the heat level required or to

" 0 " to stop the cooking zone.

NB:

Do not use a sponge which is too wet.

Never use a knife or a screwdriver.

A scraper with a razor blade will not damage the surface,

as long as it is kept at an angle of 30°.

Never leave a scraper with a razor blade within the reach

of children.

Never use abrasive products or scouring powders.

• The metal surround : to safely clean the metal surround wash

with soap and water, rinse, then dry with a soft cloth.

30° Maxi

• Before carrying out any maintenance work on the hob, allow it

to cool down.

• Only products, (creams and scrapers) specifically designed for

glass ceramic surfaces should be used. They are obtainable

from hardware stores.

• Avoid spillages, as anything which falls on to the hob surface

will quickly burn and will make cleaning more difficult.

• It is advisable to keep away from the hob all substances which

are liable to melt, such as plastic items, sugar, or sugar-based

products.

MAINTENANCE:

- Place a few drops of the specialised cleaning product on the

hob surface.

- Rub any stubborn stains with a soft cloth or with slightly damp

kitchen paper.

- Wipe with a soft cloth or dry kitchen paper until the surface is

clean.

If there are still some stubborn stains:

- Place a few more drops of specialised cleaning fluid on the

surface.

- Scrape with a scraper, holding it at an angle of 30° to the hob,

until the stains disappear.

- Wipe with a soft cloth or dry kitchen paper until the surface is

clean.

- Repeat the operation if necessary.

A FEW HINTS:

Frequent cleaning leaves a protective layer which is essential to

prevent scratches and wear. Make sure that the surface is clean

before using the hob again. To remove marks left by water, use

a few drops of white vinegar or lemon juice. Then wipe with

absorbent paper and a few drops of specialised cleaning fluid.

The control knobs can be removed for a complete cleaning.

However, you must care not to let any liquid go into the open

zones, and then to push the knobs fully on fitting back.

The glass ceramic surface will withstand scraping from flat-

bottomed cooking vessels, however, it is always better to lift them

when moving them from one zone to another.

8. CLEANING AND MAINTENANCE

9 GB-IE
