The oven temperature and heater can be

selected by turning the oven adjustment

knob to the desired temperature level.

The oven thermostat range is: 140-

270°C.

Some cookers have flame safety device

on burners. If the flame goes out, the gas

supply is automatically cut off.

4.11. GAS OVEN

•The cooker is equipped with a metal turnspit, two forks and a hook

used to support the spit.

•Instruction for use:

-Remove all accessories from the oven;

-put the deep pan on the bottom of the oven or on the lowest bench;

-stick the turnspit through the meat, centered between the two forks;

-Fix the turnspit into the drive hole located in the bottom wall, then

hang

the support hook in the drive located at the top front of the oven cavity

and around the edge of the turnspit

•Preheating is not necessary with the turnspit.

•Cooking Time Recommended in turnspit Position

4.8. COOKING TURN SPIT

Cooking time (min)

Gas Oven

Electric oven

Beef (1kg)

Lamb sheep, (1kg)

Veal, Poultry (1kg)

Por (1 kg)k

25/35

35/45

65/75

60/70

20/30

30/40

60/70

65/75

Type of food

4.10. USING THE END OF COOKING TIMER

This control enables to set the desired

cooking time (max. 90 min.) the oven will

automatically switch off at the end of the

set time.

The timer will count down from the set

time return to the “O” position and switch

off automatically.

For normal use of oven set the timer to

the position.

To set the oven ensure the timer is not on

the “O” position.

To set the cooking time, turn dial one

complete revolution and then position

the index to the required time. When the

time has lapsed, the signal will ring for a

few seconds.

4.9. USING THE MINUTE TIMER

• Press and hold the TIMER and END buttons ( and )

• Set time with buttons

• Release all buttons

ATTENTION the oven only operates if set on manual function or preset time.

N.B.: on some models the symbols are replaced by + and - .

•Sounds an alarm at the end of the

set time.

•To check how long is left to run

press the button

FUNCTION

HOW TO ACTIVE

HOW TO SWITCH IT OFF

WHAT IT DOES WHAT IT IS FOR

MINUTE

MINDER

•Allows to use the oven as alarm clock (could be activated either with

operating the oven or with out operating the oven)

•Press and hold the

button

•Press the buttons

or to set the

equired time

•Release all the buttons

•For cooking the desired recipes

MANUAL

FUNCTION

•Turn the oven function

selector to position“O”

•Enables you to operate the oven.

COOKING

TIME

•At the end of the cooking set time, the oven will switch off automatically

and an audible alarm will ring.

•When the time is elapsed

the oven will switch off

automatically. Should you

wish to stop cooking earlier

either turn the function

selector to 0, or set time to

0:00(TIMER and

buttons)

•It allows to preset the cooking

time required for the recipe

chosen.

•To check how long is left to run

press the TIMER button.

•To alter/change the preset time

press TIMER and buttons

END OF

COOKING

•This function is typically used with “cooking time” function. For example

if the dish has to be cooked for 45 minutes and needs to be ready by

12:30, simply select the required function, set the cooking time to 45

minutes and the end of cooking time to 12:30.

•Cooking will start automa-tically at 11:45 (12:30 minus 45 mins) and will

continue until the preset end of cooking time, when the oven will switch

itself off automatically

WARNING!

If the END of cooking is Selected without setting the length of cooking

time, the oven will start cooking Immediately and it will Stop at the END of

cooking time set.

•At the time set, the oven

will switch off. To switch off

manually, turn the oven

function selector to position

“O”.

•Enables you to set the end of

cooking time

•To check the preset time press

the END button

•To modify the preset time press

buttons END+

•Press and hold the

TIMER button

•Press the buttons

or to set the lenght

of cooking required

•Release all buttons

•Set the cooking

function with the oven

function selector

•Press the button

•Set the cooking

function with the oven

function selector

•Press and hold the

END button

•Press the buttons

to set the time at which

you wish the oven to

switch off

•Release the buttons

•Set the cooking

function with the oven

function selector

Setting the correct time:

•When the set time as

elapsed an audible alarm

is activated (this alarm will

stop on its own, however

it can be stopped

immediately by pressing

the button)

4.12. USE OF THE ELECTRONIC

PROGRAMMER

13 GB

50

40

30

20

10

Figure 13

90

80

70

60

50

40

30

20

10

Figure 14

Figure 15

150

180

210 240

Max

Min

WARNING : the first operation to carry out after the oven has been installed or

following the interruption of power supply (this is recognizable the display pulsating

and showing ) is setting the correct time. This is achieved as follows

In the programming of a timer with 5 buttons, for manual function, press "TIMER"

and "END" buttons simultaneously
