Important information...
Your dryer is designed to be particularly energy efficient. Its technical features include
a refrigeration circuit, which uses energy efficiently in a similar way to a refrigerator.
The dryer's heat exchanger is cleaned automatically during drying.
The fluff filter and filter in the condensate container must be cleaned regularly.
Never operate the dryer without the fluff filter and without filter in condensate container.
ʑ
Fluff filter
During drying, fluff and hair from the laundry is trapped by the fluff filter.
A blocked fluff filter may impair the heat exchange process.
The fluff filter must therefore be cleaned after every drying cycle.
Rinse regularly under running water a Page 4.
When cleaning the fluff filter, make sure that no foreign material (down, filling materials) enters
the air duct opening. If necessary, clean the drum beforehand with a vacuum cleaner.
If foreign material should still enter the air duct a call the after-sales service.
ʑ
Filter in the condensate container
The filter in the condensate container cleans the condensation. This condensation is required
for the automatic cleaning process. The filter should be cleaned regularly under running
water. Empty the condensate container before cleaning the filter a Installation and
maintenance instructions, Page 3.
ʑ
Fabrics
Do not dry any fabrics that have come into contact with solvents, oil, wax, grease or paint:
e.g. hair styling products, nail varnish remover, stain remover, cleaning solvent, etc.
Empty all pockets.
Do not dry non-breathable fabrics.
Avoid drying laundry items that produce a lot of fluff.
Woollens should be refreshed or dried using the woollens programme only.
9
Consumption values table
Programme
Spin speed which
is used for spinning
the laundry
Duration** Energy consumption**
Cottons 8 kg 4 kg 8 kg 4 kg
+üC/board Dry*
1400 rpm 167 min 105 min 1.22 kWh 0.73 kWh
1000 rpm 187 min 118 min 1.41 kWh
0.84ükWh
800 rpm 207 min 131 min 1.60 kWh
0.95ükWh
|ücIron Dry*
1400 rpm 109 min 69 min 0.66 kWh 0.39 kWh
1000 rpm 129 min 81 min 0.84 kWh 0.50 kWh
800 rpm 149 min 94 min 1.03 kWh 0.61 kWh
Easy-Care 3.5 kg 3.5 kg
+cC/board Dry*
800ürpm
57 min 0.43 kWh
600 rpm 69 min 0.50 kWh
* Programme setting for testing in accordance with the applicable EN61121 standard.
** The values may differ from those specified, depending on the type of fabric, composition of
laundry to be dried, residual moisture in the fabric and the amount of laundry being loaded.
Most efficient programme for cotton fabrics
The following "standard cottons programme" (identified with ) is suitable for drying normal, wet
cotton laundry and is most efficient in terms of its combined energy consumption for drying wet
cotton laundry.
Standard programme for cottons in accordance with current EU regulation 932/2012
Programme + Drying target Load Energy consumption Programme duration
Cottons + C/board Dry 8 kg/4 kg 1.41 kWh/0.84 kWh 187 min/118 min
Programme setting for testing and energy labelling in accordance with Directive 2010/30/EU.
Power consumption when switched off 0.13 W
Power consumption when ready for use (left-on mode) 0.13 W
10
Normal noises
During drying, the compressor and the pump generate some noise which is entirely normal.
The compressor in the dryer may
occasionally generate a humming noise.
The volume and pitch of this may vary
depending on the selected
programmes and the progress of the
drying.
The compressor in the dryer is ventilated
from time to time, which creates a whirring
sound.
The automatic cleaning process causes
a clicking noise.
The process of pumping the condensation
into the condensate container generates
pumping noises.
11
What to do if ...
If you cannot rectify a fault yourself (e.g. by switching the dryer off/on), please contact our
after-sales service.
We will always find an appropriate solution and will avoid unnecessary visits by engineers.
Trust the expertise of the manufacturer and rest assured that the repair will be carried out
by trained service technicians using original spare parts.
The contact details of your local after-sales service can be found in the enclosed after-
sales service directory:
– GB 3 448 928 979 (Calls charged at local or mobile rate)
– IE 01450 2655 (0.03 € per minute at peak. Off peak 0.0088 € per minute.)
When contacting the after-sales service, please specify the product number (E-Nr.) and
production number (FD) of your appliance(see inside of door).
Switch the dryer off using the programme selector and unplug the mains plug from the
socket.
ʠ
Please empty condensate
container appears, and drying
is interrupted.
Empty the condensate container aPage 4.
Is the condensation drain installed? aCondensation
drain hose blocked a check and clean the hose.
Stopper in the condensate container? aseparate
Instructions for condensation drain.
Is the filter in the condensate container dirty? a Clean
the filter in the condensate container a Installation and
maintenance instructions, Page 3.
Press any button to resume the programme.
Press the $(Start/Pause) button again.
ʠ
Residual water in the
condensation container
despite the dryer being
connected to the
condensation drain.
Not a fault. If the condensation drain is installed,
residual water remains in the condensation container
due to the dryer's self-cleaning function.
ʠ
Please clean lint filter is
displayed.
Clean the fluff filter a Page 4.
Press the $(Start/Pause) button again.
ʠ
Heat exchanger is being
rinsed is displayed in the
display panel.
Not an error. Automatic cleaning of the heat exchanger.
Do not empty the condensate container during
the cleaning process.
ʠ
Dryer does not start. Has the $(Start/Pause) button been pressed?
Door closed? Ambient temperature greater than 5 °C?
ʠ
Water is leaking out. Make sure the dryer is level. Push the condensate
container back in until it locks fully into place.
12
What to do if ...
ʠ
Laundry is not dried correctly
or is still too damp.
After the end of the programme, warm laundry feels
damper than it actually is. Spread the laundry out and
allow the heat to disperse.
Finely adjust the dryness level – this extends the drying
time but does not increase the temperature. Your
laundry will become drier.
Select a programme with a longer drying time or
increase the drying level. This does not increase the
temperature.
Select a time programme for extended drying of laundry
that is still damp.
If you have exceeded the maximum load for the
programme, the laundry may not be dried correctly.
Clean the moisture sensor in the drum. A fine layer of
limescale may adversely affect the performance of the
sensors and your washing will not dry properly.
Drying has been interrupted as a result of a power cut,
because the condensate container is full or because the
maximum drying time has been exceeded.
ʠ
Drying time too long. Clean the fluff filter under running water a Page 4.
Insufficient supply of air a Ensure that air can circulate.
Air inlet may be obstructed? Clear the inlet
a Installation and maintenance instructions, Page 1.
Ambient temperature higher than 35 °C a Ventilate the
room.
ʠ
The humidity in the room
increases significantly.
Make sure the room is sufficiently ventilated.
ʠ
Power failure. Remove the laundry from the dryer immediately and
spread out. This allows the heat to dissipate. Be careful
as the door, the drum and the laundry may be hot.
ʠ
Other intermittent noises and
vibrations.
Normal noises a Page 10.
13
Safety instructions
Emergency
– Pull the appliance plug out of the socket immediately or disconnect the fuse.
ONLY use the
dryer...
– in rooms inside the house.
– to dry fabrics.
The dryer must
NEVER...
– be used for purposes other than those described above.
– be modified in terms of its technology or properties.
Hazards
– The dryer must not be used by children or persons who have not been instructed
in its use.
– Do not leave children unsupervised near the dryer.
– Keep pets away from the dryer.
– Remove all objects from pockets, and lighters in particular a Risk of explosion.
– Do not lean or sit on the door a Risk of tipping.
– Open the door carefully. Hot steam may escape. Fabrics and drum may be hot
a Risk of burns.
Installation
– Secure loose leads or hoses, otherwise there is a risk of tripping.
– Below 0 °C there is a possibility of frost damage.
Mains
connection
– Connect the dryer to an AC earthed socket according to specifications, otherwise
it cannot be guaranteed that the appliance is completely safe.
– The cable cross-section must be sufficient.
– Only use earth-leakage circuit breakers with the following symbol:
– The appliance plug and socket must be compatible.
– Do not use multiple plugs/connectors and/or extension cables.
– Do not touch or hold the appliance plug with wet hands
a Risk of electric shock.
– Never pull the appliance plug out of the socket by its cable.
– Do not damage the mains lead a Risk of electric shock.
Operation
– Only load the dryer as recommended in the programme descriptions
(Programmes/fabrics, Page 1 and Programme overview, Page 7).
Check the contents before you switch the dryer on.
– Do not use the dryer if the laundry has been in contact with solvents, oil, wax,
grease or paint (e.g. hair styling products, nail varnish remover, stain remover,
cleaning solvent, etc.) a Risk of fire/explosion.
– The tumble dryer is not to be used if industrial chemicals have been used for
cleaning.
– Dust (e.g. coal dust, flour) poses a danger: Do not use the dryer
a Risk of explosion.
– Do not turn off the dryer until the drying process ends, unless the laundry will be
removed quickly and spread out, so that the heat can dissipate
– Do not put laundry containing foam material/rubber in the dryer
a elastic material may be destroyed and the dryer may be damaged due to
possible deformation of the foam material.
– Light things, such as long hair, may be sucked into the air inlet of the dryer
aRisk of injury.
– Final part of a tumble dryer cycle occurs without heat (cool down cycle), to ensure
that the items are left at a temperature that ensures that the items will not be
damaged.
– Switch off the dryer once the programme has ended.
– The distilled water/water from condensation is not drinking water and may be
contaminated with fluff.
Defect
– Do not use the dryer if it is defective or if you suspect that it is.
Repairs must only be carried out by the after-sales service.
– Do not use the dryer if the mains cable is defective. To avoid danger, only have
the defective mains cable replaced by the after-sales service.
Spare parts
– Only use genuine spare parts and accessories for safety reasons.
Disposal
– Dryer: Pull out the appliance plug, then cut off the mains cable from the appliance.
Dispose of the appliance at a municipal waste disposal facility.
– Packaging: Keep all packaging out of reach of babies and children
a Risk of suffocation.
– The dryer's heat exchanger contains fluorinated greenhouse gas in a hermetically
sealed unit (R407c) a Dispose of this properly. Capacity: 0.315 kg.
– All materials are environmentally sound and can be reused.
Dispose of in an environmentally-responsible manner.
en Instruction manual
Dryer
WTY88718IT
Loading…
Valutazione
Facci sapere che cosa pensi della Bosch WTY88718IT Asciugatrice valutando il prodotto. Vuoi condividere la tua esperienze con questo prodotto o porre una domanda? Ti preghiamo di lasciare un commento al fondo della pagina.Maggiori informazioni su questo manuale
Comprendiamo che sia bello avere un manuale cartaceo per i tuoi Bosch WTY88718IT Asciugatrice. Puoi sempre scaricare il manuale dal nostro sito web e stamparlo tu stesso. Se desideri avere un manuale originale, ti consigliamo di contattare Bosch. Potrebbero essere in grado di fornire un manuale originale. Stai cercando il manuale del tuo Bosch WTY88718IT Asciugatrice in un'altra lingua? Scegli la tua lingua preferita sulla nostra home page e cerca il numero del modello per vedere se è disponibile.
Specifiche
| Marca | Bosch |
| Modello | WTY88718IT |
| Categoria | Asciugatrici |
| Tipo di file | |
| Dimensione del file | 3.08 MB |
Tutti i manuali per Bosch Asciugatrici
Altri manuali di Asciugatrici
Domande frequenti su Bosch WTY88718IT Asciugatrice
Il nostro team di supporto cerca informazioni utili sul prodotto e risposte alle domande più frequenti. Se trovi un’inesattezza nelle nostre domande frequenti, ti preghiamo di farcelo sapere utilizzando il nostro modulo di contatto.
Perché il tamburo dell’asciugatrice è più grande di quello della mia lavatrice, anche se hanno la stessa capacità? Verificato
Per asciugare correttamente il bucato, l’asciugatrice ha bisogno d’aria. Questo richiede spazio ed ecco perché il tamburo deve essere più grande.
È stato utile (2994) Per saperne di piùQual è la differenza tra un essiccatore a condensazione e un essiccatore ventilato? Verificato
In un essiccatore a condensazione il vapore d’acqua condensato viene scolato e raccolto in un serbatoio interno. In un essiccatore ventilato, l’acqua calda e umida viene scolata tramite un tubo all’esterno, come fuori dalla finestra ad esempio. Un essiccatore ventilato è meno costoso di un essiccatore a condensazione.
È stato utile (857) Per saperne di piùPosso impilare l’asciugatrice e la lavatrice? Verificato
Sì, in generale l’asciugatrice e la lavatrice possono essere impilate in caso di modelli a carica frontale. Tuttavia, si consiglia di utilizzare una base di sovrapposizione. In questo modo si evita che il dispositivo in alto possa vibrare e cadere oltre a causare danni al dispositivo sottostante.
È stato utile (690) Per saperne di piùPosso collegare l’asciugatrice a una prolunga? Verificato
Gli elettrodomestici che necessitano di molta energia, come le asciugatrici, non possono essere collegati con una prolunga. Verificare il consumo energetico dell’asciugatrice, indicato in Watt, e controllare che la prolunga possa reggerlo. Esistono delle prolunghe con cavi più spessi che sono costruiti per reggere elettrodomestici più potenti.
È stato utile (534) Per saperne di piùQual è la differenza di utilizzo tra una lavasciuga e una lavatrice e asciugatrice separate? Verificato
Il più grande vantaggio di una lavasciuga è che occupa meno spazio. Tuttavia, un'asciugatrice separata sarà in grado di asciugare più di una lavasciuga. Una lavasciuga utilizza anche relativamente più energia e richiede più tempo.
È stato utile (523) Per saperne di più
Partecipa alla conversazione su questo prodotto
Qui puoi condividere cosa pensi di Bosch WTY88718IT Asciugatrice. Se hai una domanda, leggi prima attentamente il manuale. La richiesta di un manuale può essere effettuata utilizzando il nostro modulo di contatto.
