Manuale Bauknecht ETI 6740 IN/1 Piano cottura

Manuale

15

Switching on and adjusting cooking zones

After switching on the hob and positioning the pot on the

chosen cooking zone, adjust the heat setting using the

button +. When switched on, the display shows level 5.

Each cooking zone has different heat settings that can be

adjusted using the buttons +/-, which go from “1”: min.

heat setting to “9”: max. heat setting. Some cooking zones

have a fast boil function (Booster), shown on the display

with the letter “P”.

Fast boil function (Booster)

This function, only present on some cooking zones, makes

it possible to exploit the hob's maximum power (for

example to bring water to the boil very quickly). To select

this function, press the button “+” until “P” appears on the

display or, after switching the hob on, press the “-” button

for the selected cooking zone. In this case too, “P” appears

on the display. After 10 minutes' use of the booster

function, the appliance automatically sets the zone to

level 9.

Switching off cooking zones

Select the cooking zone to be switched off by pressing the

“+” or “-” key (a dot lights up at the bottom right hand

side of the heat setting indicator).

Press the key “-” to set the level to “0”.

The cooking zone can also be switched off by pressing keys

“+” and “-” at the same time. The cooking zone switches

off and the residual heat indicator “H” lights up

Child safety

This function locks the hob controls to prevent accidental

switching on by children. To activate the child safety

function, switch on the hob then press and hold the

button for three seconds: an acoustic signal and a

luminous indicator under the key symbol signal activation.

The control panel is locked with the exception of the OFF

function. To unlock the controls, repeat the child safety

activation procedure. The illuminated dot switches off and

the hob is active again.

The presence of cleaning water, liquid spilled

from pots or any objects resting on the button

below the symbol can accidentally activate or

deactivate the child safety function.

Child guard accessory AMH 122

This accessory can be obtained from the After-sales

Service under Part N° 481931018436

Timer

The timer can be used to set a max.

cooking time of 99 minutes (1 hour and

39 minutes) for one cooking zone only.

Select the cooking zone to be used with

the timer (an illuminated dot appears to

the bottom right hand side of the heat setting indicator on

the display), then set the desired cooking time using the

buttons “+” and -“-” of the timer function (see figure

above). A few seconds after the button is pressed, the

timer begins the countdown (the luminous dot of the

selected cooking zone starts flashing). Once the set time

has elapsed, an acoustic signal sounds and the cooking zone

switches off automatically.

To deactivate the timer, press the button “-” until the

display shows “0:0” or press the buttons “+” and “-” of the

timer at the same time.

Important! The timer function can only be

used with one cooking zone at a time.

Minute minder

The minute minder can only be used when the hob is not

in use and allows a maximum setting of 99 min.

Press the button “+” below the timer indicators: the

display shows the minutes for setting.

Select the time desired using the buttons + and -.

After a few seconds the minute minder starts to count

down. Once the set time has elapsed an acoustic signal

sounds.

Important! The minute minder function can

only be used when the hob is switched off; if it is

then switched on, the minute minder countdown

is automatically cancelled.

Control panel warnings.

Residual heat indicator.

The hob is fitted with a residual heat indicator for

each cooking zone. These indicators alert the user

when cooking zones are still hot.

If the display shows , the cooking zone is still hot.

If the residual heat indicator of a given cooking zone is lit,

that zone can be used, for example, to keep a dish warm

or to melt butter.

When the cooking zone cools down, the display switches

off.

Incorrect or missing pot indicator.

The hob features an automatic pot detection

system for all cooking zones. If no pot is detected,

the display with the cooking zone power level

indicator flashes. Make sure the pot is correctly

positioned and that it has the characteristics given in the

section “Before use”.

Button -

Heat setting indicator

Selected cooking zone

indicator

Button +

Cooking zone

positioning
