Manuale ADE BA 719 Tanja Bilancia

Manuale

Thank you for purchasing this high-quality product made by ADE. You have acquired a

set of scales that meet the highest technical standards and are of proven quality.

Please read these operating instructions carefully before using the product for the first

time and keep them in a safe place where you can find them whenever you need the

information contained in the instructions.

1. How does the body analyser work?

Through this new revolutionary scale, you will be able to get information about your body

composition with reference to your weight, body fat %, body water % and muscle mass

%. First, you have to enter once your personal data like body height, age, gender under

your selected personal memory location. Afterwards a measurement is as simple as on a

normal bathroom scale. You have only to push your personal memory location, step on

the scale and within a few seconds, your measured values will be indicated. The analysis

based on the measurement of the body’ s electrical resistance. A low, safe electrical

signal passes freely through fluids contained in lean tissue, such as muscle and blood,

but meets resistance passing through fat tissue. The body analyser accurately measures

the resistance and with reference to your personal data use it to calculate elements of

body composition.

2. How to use

If possible, the measurement should be done undressed but always barefoot.

By nature, a body is subject of fluctuations (for example loss of water after taking

exercise or after a sauna visit, after a meal, etc.). To enable comparable readings it is

important to take the measurements as possible always under the same conditions.

In order to ensure that the results of analysis are accurate and consistent, please keep

the measurement conditions constant always at the same daytime. In the morning,

directly after you’ ve woken up, your body will be dehydrated and also the majority of fluid

will be stored in the central trunk area. This means that the resistance is relatively high

because of the poor conductivity in the body. By intensify moving during the day

progresses the fluid becomes more evenly distributed through the limbs and increasing

the accuracy of the readings. To get a realistic result it is important to take your readings

at the same time and under the same conditions every day. The easiest way to stick the

rule, measure always in the morning, 15 minutes after you’ ve got up, either before or

after you’ ve gone to the bathroom.

In spite of a very low electrical signal, this body ana lyzer is not suitable for persons

with hea rt pacemaker or other electronic medical implants! There is no risk for

persons with none electronic implant for instance a titanium plate in the knee. However,

metal conducts the electric current extremely well and therefore the scale implicates the

body fat value “ beautified” – means the actual body fat value is higher as indicated.

However, tendencies may be determined as well.

7. Error Messages

“ FFFF“ = Overload display – The 150 kg maximum capacity of the scales

has been exceeded. Immediately remove the load from the

scales; otherwise, the load cell could be damaged.

“ Lo“ = Indication that the battery is flat – Please replace the batteries

with four 1.5 V type AA.

8. Technical Data

Capacity x graduation: max. 150 kg x 100 g

Display resolution: body fat: 0.1%

Display resolution: body water: 0.1%

Display resolution: muscle mass: 0.1%

Personal memory loc.: 12 positions

Age: 9 – 99 years

Body height: 90 – 250 cm

Dimensions: 330 mm x 330 mm x 36 mm

Batteries: 4 x 1.5V AA (included)

Subject to technical changes due to further-development of the product.

5. Guarantee

ADE guarantees to rectify any defects due to material or manufacturing defects by means

of repair or replacement free of charge for a period of three years. At the time of purchase,

please get the retailer to fill in and stamp the guarantee card. In the case of guarantee

claims, please return the scales to your retailer including the guarantee card and stating

the reasons for the claim.

CE conformity

This device is interference-suppressed in accordance with

the applicable EU directive 2004/108/EC

Note: Extreme electromagnetic influences, e.g. when operating radio communication

equipment is being operated next to the scales, can affect the displayed value. When the

interference is over, you can use the product for its intended purpose again; it may be

necessary to switch it on again.
