Thank you for choosing Silva Tipi headlamp. This compact

headlamp is designed for camping, hiking and DIY (Do It Yourself)

purposes where a compact and “easy to carry” product is essential.

The Tipi headlamp’s special feature – the removable light unit –

makes it a versatile partner as it converts from a headlamp to a

torch (or back) within “a second”.

PRODUCT OVERVIEW

The Tipi headlamp consists of the following parts:

• Light unit with battery compartment

• Headband bracket – where the light unit is attached

• Headband

• 3 pcs AAA batteries

• Quick guide

BEFORE USE

INSERT BATTERIES

1. Pull out the light unit from the light body

2. Insert the 3 pcs AAA batteries

3. Assemble by putting back the light unit into the light body

4. Ready!

ADJUST THE HEADBAND

The elastic headband is designed to give a comfortable fit. Adjust

the headband by moving the sliding buckle to fit it onto your head.

DURING USE

SWITCH ON YOUR HEADLAMP

On the side of the headlamp body there is a push button which

controls all light modes.

Each press on the button gives you the following light:

1. Turns the headlamp ON with the LEDs in maximum power.

2. Puts the headlamp in min mode

3. Starts over from 1

To turn OFF the headlamp; press and hold the button for 1 second.

The flash function, which is used to attract attention, is started

from OFF mode by pressing and holding the button for 1 second. To

turn OFF; press and hold the button for 1 second.

AFTER USE

MAINTENANCE

To make sure you get maximum performance from your Tipi head-

lamp, clean it regularly with a damp cloth.

Headband cleaning – wash in washing machine at 40º C.

If stored for a long period the batteries should be removed.

TECHNICAL SPECIFICATIONS

Weight (including batteries): 82g

Battery type: 3 pcs AAA Alkaline

Light distance (Max/Min): 25 m/12m

Lumen: 20

Burn time: (Max/Min/Blink): 40h/80h/120h

Water resistance: IPX4

Operative temperature range: -20 - +60 ºC

PROTECT THE ENVIRONMENT.

Headlamp and batteries should be recycled and must not be thrown

in the regular trash. Dispose these items in accordance with ap-

plicable local regulations.

WARRANTY

Silva warrants that, for a period of two (2) years, your Silva Product

will be substantially free of defects in materials and workmanship

under normal use. Silva’s liability under this warranty is limited to

repairing or replacing the product. This limited warranty extends

only to the original purchaser.

If the Product proves defective during the Warranty Period please

contact the original place of purchase. Make sure to have your proof

of purchase on hand when returning the product. Returns cannot

be processed without the original proof of purchase. This warranty

does not apply if the Product has been altered, not been installed,

operated, repaired, or maintained in accordance with instructions

supplied by Silva, or has been subjected to abnormal physical or

electrical stress, misuse, negligence or accident. Neither does the

warranty cover normal wear and tear. Silva is not responsible for

any consequences, direct or indirect, or damage resultant from use

of this product. In no event will Silva’s liability exceed the amount

paid by you for the product. Some jurisdictions do not allow the ex-

clusion or limitation of incidental or consequential damages, so the

above limitation or exclusion may not apply to you. This Warranty is

valid and may be processed only in the country of purchase.

For more information please visit www.silva.se

FULL VERSION MANUAL

tipi

3

5

5

6

7

7

2

4

4

6

Art.no 37314-1 (Green)

Art.no 37314-2 (Orange)

Visit: www.silva/enviroment

for more information about the

Waste Electrical and Electronic

Equipment (WEEE) Directive.
