Manuale Rameder Xtreme 600 Box da tetto

Manuale

ROOFBOX ASSEMBLING INSTRUCTION "ULTRARAPID"

1

3

40 mm

MAX

70 mm

2

WARNING!

Before every departure check your roofbox is well fasten to the roofbars, the cover is

locked by the locking system and by safety clips.

USE

Every time you carry loads on your vehicle remember that you are entirely responsable for your security and that of others.

Be carefull in assembling the roofbox on the bars and in using it properly.

IMPORTANT INFORMATION

A) Read carefully the assembling instruction and follow them strictly. Always keep them. In case of no respect or incorrect use

of these instructions, the manufacturer disclaims all responsability.

B)

Before every departure and frequently during your journey make sure your roofbox is fasten to the bars of the vehicle.

C) While you are driving, always remember the considerable air pressure on the roofbox, in particular on motorways and with

atmospheric conditions of strong wind. Drive carefully.Your roofbox is planned for being used to normal speed.

The maximum speed advises by the manufacturer is 130 Km/h.

D)

The maximum load is Kg. 50. Never exceed the weight and size indicated on the vehicle booklet

(Maximum load = roofbars weight + roofbox weight + load).

E) In case of no use of your roofbox dismount it from your vehicle.

You will save fuel.

F) To clean your roofbox only use a sponge with water and soap. Do not use alcohol or solvent.

PATENDED

ASSEMBLING THE ROOFBOX

-

Place your roofbox on the roofbars.

-

Be sure that the roofbox is properly situated on the vehicle axis.

-

Verify that the roofbox is placed in the centre of the roofbars.

fig. 1)

- Unblock the safety lock (fig. 1/A) and upright the handle (fig. 1/B).

fig. 3)

- Screw the handle clockwise to bolt the hook and push the handle down to lock the system

(fig. 3/E)

.

In case the system does not lock, lift the handle up, screw or unscrew (if the

locking is too hard) and repeat the procedure.

- Block the safety lock (fig. 3/F).

Check carefully that the system is well fixed and the roofbox does not slide

from the roofbars.

- After mounting the roofbox, insert the laggage straps through the openings of the fixing

group unit

(fig. 2/G).

fig. 2)

- Unscrew the handle anticlockwise to release the

metal hook

(fig. 2/D) so to proceed to next step.

- Slide the fixing system

(fig. 2/C) to the right or to the

left to find the suitable position for the metal hook on

the roofbar

(fig. 2/D).

WARNING!

The fixing system can be

mounted on roofbars with

a maximum dimension

of 70 mm.x 40 mm.

B

A

D

C

G

F

E
